Vi sai chống trượt - Vi sai Torsen

Vi sai chống trượt - Vi sai Torsen

Mô phỏng cơ cấu Man bằng Inventer

Cơ cấu Man trong Inventer

Springs Former

9 Axes CNC Spring Former, producing 6mm spring steel wire double torsion spring for agricultural machine.

Coil Springs

Located at Pedders Head Office, the Pedders Coil Spring Manufacturing Plant, holds the Quality Standard QS 9001. The goal for Quality System Requirements QS-9001 is the development of fundamental quality systems that provide for continuous improvement, emphasising defect prevention and the reduction of variation and waste in the supply chain. Pedders is the only aftermarket supplier of coil springs in Australia to hold this quality certification.

Cơ cấu Cardan

Cardan Universal Joint

Nối trục vòng lò xo

Coples de rejillas Steelflex de Rexnord Falk

Nối trục đàn hồi

Curved jaw couplings are well suited to servo applications where accuracy of torque transmission is required. The three-piece design, consisting of curved jaw hubs which are press fit into an elastomeric spider, allows the coupling to operate with zero-backlash

Vít me - đai ốc con lăn SKF

Compact inverted roller screws are designed to provide powerful electromechanical actuation where compactness and high load capability are prerequisites.

Vít me - đai ốc bi SKF

Ball screws make use of different systems to circulate balls within the nut. The recirculation system depends on the properties of the screw. The recirculation takes place through a tube inside the nut.

Vít me - đai ốc: Bàn kẹp

Precision Vice Grip made with AutoDesk Inventor 2009

Hệ thống tự động với hộp giảm tốc trục vít

Worm Gear Speed Reducer

Hypoid gearing - bánh răng côn xoắn trục chéo nhau

Export Worldwide Custom Gear Manufacturer since 1942 Gleason Hypoid Gear Generator Machine Cutting Spiral Bevel Gear Z:22, Dp 2.54, Fw 4.750, Gear Ratio 3.45, Pair Z:76, Steel 8620 Engranajes Conicos Mexico City

Spiral bevel gear - bánh răng côn xoắn

Gleason or Klingelnberg spiral bevel gears cut at on universal CNC milling machines with software from Spiral Bevel Corporation. Reference from engineering book: "Direct Digital Simulation for Gears".

Crossed helical gear - bánh răng trụ xoắn

Planetary gearing (Epicyclic gearing) - bánh răng hành tinh

Planetary gear set in motion. First the planet carrier is held stationnary, then the sun is held stationnary, finally the ring gear is held stationnary.

Harmonic drive (strain wave gearing) - bánh răng sóng

Simulation eines Zykloiden-Kurvenscheibengetriebes mit Catia V5 R18

Bevel gear - bánh răng côn

Dentatura Pignone Conico modulo 3,9 su MODUL ZFTK 500x10 Materiale: 18Ncd5

Bánh răng chữ V

Helical spur gear - bánh răng trụ răng nghiêng

Some tests with the new RC-gear Skin look fabulous incredibly strong and lighter than its competitors The RC-Skin Combo is a great product for Racers & Bashers

Spur gear - bánh răng trụ răng thẳng

CraftWorks does it again with another great product. Their alloy spur gear carrier is a great looking product that is stronger and lighter then the stock carrier and it looks GREAT!
